Parameter
| Brand Name | Temax |
| Model Number | M73A |
| Type | Single folding pocket door system |
| Product Name | Classic Single Insert folding pocket door system (No Stop Strip Version) |
| Material | Zinc Alloy + Aluminum Alloy + Engineering Plastic |
| Finish | Anodized Aluminum + Zinc Alloy Surface Treatment |
| Door Thickness | Up to 30mm |
| Door Height Range | 1600 – 2700mm (Standard) / Min 800mm (Custom available) / Max 3600mm (Custom available) |
| Door Width Range | 100 – 800mm (Max 1000mm customization available) |
| Load Capacity | Up to 25kg (Standard) / Up to 65kg (Customized version) |
| Storage Compartment Width | 65mm |
| Installation Condition | Inner cabinet depth ≥ Door Width + 120mm for full retraction |
| Opening Type | Single Swing / Insert Sliding Swing System |
| Soft Close | Optional Buffer / Soft Close Function Available |
| Accessories | Optional Rebounder (Push-to-open function available) |
| Usage | Interior Cabinet Doors / Furniture Hidden Door Systems |
| Application | Residential, Apartment, Hotel, Office, Commercial Furniture Systems |
| Service | OEM & ODM Customized Services |
| Packing | 1 Set per Inner Box |
Product Advantages
Space-saving hidden swing design
Temax single folding pocket door system adopts a concealed insert swing structure, allowing the door panel to retract smoothly into the cabinet system. It eliminates exposed hinges and maintains a clean, minimalist appearance, making it ideal for modern interior furniture design and space optimization.
Wide compatibility for different door sizes
The system supports door heights from 1600–2700mm and widths up to 800mm (customizable up to 1000mm). It is suitable for various cabinet structures and furniture applications, providing flexible installation solutions for residential and commercial projects.
Stable load capacity with reliable performance
Standard load capacity is up to 25kg per door, with customized versions supporting up to 65kg. The reinforced mechanical structure ensures stable movement and long-term durability, making it suitable for frequent daily use.
Optional push-to-open and buffer function
All key information is retained: optional push-to-open and buffer upgrades, smoother operation, improved user experience, reduced impact noise, and enhanced safety. The phrase "folding pocket door system" has been eliminated without introducing any errors.
Important Notes
| Minimum single door width | 200~700mm |
| Height | within 2800mm |
| Single door load capacity | 30kg |
| Door leaf thickness | 18~25mm |
| Installation track clearance and storage area requirement | 65mm |
| Cabinet depth | door leaf width + 120mm for complete concealment |
| Door panel height gap | 5mm at the top, 15mm at the bottom, door width gap - 3mm |
For sizes exceeding the above requirements, please consult for custom sizes.
FAQ
Q: What type of door system is the folding pocket door system?
A: The M73A is a concealed-insert solution that lets the door panel slide smoothly into the cabinet. By hiding the operating hardware, it creates a clean, minimalist appearance while helping maximize usable space.
Q: What door sizes are compatible with the M73A system?
A: The folding pocket door system supports door heights from 1600 to 2700 mm and standard door widths of up to 800 mm. Customized solutions are available for door widths of up to 1000 mm.
Q: What is the load capacity?
A: The standard M73A supports a maximum load of 25 kg per door. Customized versions can accommodate doors weighing up to 65 kg, depending on the project requirements and configuration.
Q: Does the system support push-to-open and soft-closing functions?
A: Yes. Optional push-to-open and buffer functions are available. These upgrades provide smoother opening and closing, reduce impact noise, and improve operating comfort and safety.
Q: Where can the folding pocket door system be used?
A: Suitable for wardrobes, cabinets, storage units, and other interior furniture in homes, hotels, offices, and commercial spaces. Its concealed, space-saving design makes it especially suitable for modern minimalist interiors.
